TK 5K

Heat Pumps for Aquariums

Heat Pumps for Aquariums

Efficient Cooling Technology
The exclusive use of internationally recognized, high-performance rotary compressors and of the titanium heat exchanger, ensures high performance and low energy consumption. The set of technologies used allows you to decrease noise levels and achieve the highest COP - coefficient of performance - contributing to significant energy savings.
Digital Thermostat
The setting of functions is intuitive and the temperature detection is accurate, resolution 0.5°C/1°F. The setting range is 5°-40°C (41°F-104°F) and there is a closed loop temperature control system with high accuracy and extremely tight differential 2°C/5°F. Displayed temperature is in °C or °F and there are security alarms. Possibility to control remotely the display using supplied cable, degree of protection IPX4.

Efficient Design
The chiller is characterized by a solid structure, designed to provide a perfect oxidation protection and therefore perfect for use with salt water.
Unique Features
These units are also suitable for industrial applications and outdoor installation. Vertical ventilation ensures optimal operation even when working in harsh environments.
Water temp. Ambient temp. Working mode Cooling Capacity COP**
25°C - 77°F* 38°C - 100°F Cooling 5,8KW 2,8





* The values reported in the table refer to the following conditions: heating load of 0.5 w/lt.
** Coefficient of performance
Voltage Frequency Gas Weight Ambient temperature Power Consumption
230V 50Hz - 1ph R410A 174,17 lb 5°C - 38°C / 41°F - 100°F 2030W
115V 60 Hz - 1 ph
R410A 174,17 lb 5°C - 38°C / 41°F - 100°F 2080W
All data are approximate and may be changed without notice by TECO.
